Molicel P42A 21700 4200mAh 3.6V Li-ion Battery Cell

Molicel INR-21700-P42A 21700 Lithium-Ion Battery Cell

Need a compact rechargeable cell for a demanding build? The Molicel P42A combines a listed 4200mAh typical capacity with a 3.6V nominal voltage and a 45A continuous discharge rating in the 21700 format. Its flat-top design can suit compatible high-current battery packs, including drone projects, when the pack is designed for this specific cell.

Specifications

• Model: INR-21700-P42A
• Size: 21700
• Top style: Flat top
• Typical capacity: 4200mAh; the previous listing also stated a 4000mAh minimum
• Continuous discharge rating: 45A, as listed in the original specifications
• Nominal voltage: 3.6V
• Protection: Unprotected cell
• Rechargeable: Yes
• Approximate dimensions: 21.40mm × 70.00mm
• Approximate cell weight: 67.8g

Molicel ultra-high power series

The original listing highlights high discharge current, low impedance, fast-charge capability, thermal stability and low-temperature operation down to -40°C as features of the series. Check the manufacturer's cell datasheet for the conditions and limits that apply to your application; cycle life and usable performance vary with current, temperature and charging conditions.

For your build

When planning a drone or other high-current pack, confirm the cell dimensions, current demand, charging method and protection requirements first. This is an unprotected lithium-ion cell, so use a suitable charger and battery-management protection, and leave pack assembly to someone qualified to work with lithium-ion cells.

Package contents

1 × Molicel INR-21700-P42A 3.6V lithium-ion battery cell.
